the catalogue #190
1964       King Step Tail    9 ft 6"
#190
MANUFACTURE
MANUFACTURER: King Surfboards/ Graham King Surfboards Princes Highway, Kirrawee, NSW
SHAPER:  Unknown
DESIGN: Step Tail - Hydro Board - Hydroplane Board - Scorpion Tail
DESIGNER: John Kelly
SPECIFICATIONS
CONSTRUCTION
Foam blank, 3/8 stringer on bottom, wedge stringer on deck - 1" at nose, 2" at tail.
The two outer laminates must be inlays.
DIMENSIONS
Length:
9
ft  6 inches
Width:
 20
inches
Wide Point:
 0
inches
Nose :
15 3/4
inches
Tail:
14 3/4
inches
Thickness:
2 3/4
inches
Pod:
  inches
Nose Lift:
  inches
Tail Lift:
  inches
Weight
  kilos
Volume:
  litres
Tail to Step:
  inches
FEATURES
Nose: Round
Tail: Square
Deck: Flat
Bottom: Flat, with step in bottom
Rails: Round  fat 50/50  to tapered 50/50 in tail .
Rocker: Flat - step
FIN
Original fin missing , replaced by 1970's Bahne Box.
(Multifins?) and Plastic fin.
Replacement fin :
Reverse D.
10 1/2" base  9" high.
Laminated 10oz cloth.
Set at the tail step.
DECOR
DECALS
Deck: King Surfboards with address and phone number,.Black and yellow in rectangle with crown grahic at tail.
Bottom: King Surfboards with address and phone number,.Black and yellow in rectangle with crown grahic. Forward of fin.
Damaged by the added fin box and covered in restoration.
MARKINGS
Deck: None
Bottom:
COLOUR
Deck
Pre-restoration : non original white paint
Post-restoration : Mid blue with dark blue rails and black pinlines
Bottom
Pre-restoration : non original white paint
Post-restoration : Mid blue with dark blue rails and black pinlines
NOTES
BOARD HISTORY
Collected by Daniel Bond from  local NSW Central Coast markets,in 2002, cost $200.
 The board was in poor condition and covered with non-original white paint..
 Possible tail section missing.
 Original fin missing , replaced by 1970's Bahne-type fin-box (Multifins?) and plastic fin.
 See pre- and post- restoration photographs below.
 Restoration details
The condition of this board prior to restoration, on a scale of 1-10 would have been 2-21/2.
The board was white all over.
Probably not original because it covered the manufactures logo and the foam was quiet brown.
It had major dings on the tail and nose, stress marks on the bottom, and fractures and dings all around the rails.
The board was in such a poor condition there was no choice but to do a full pigment job.
All the pigment / gelcoat was sanded off revealing the "King " logo and the wedge stringer on the deck.
 The fin box had to be removed and the step area rebuilt.
The rails had to be faired and glassed, stress marks and dings repaired, and a new fin glassed in.
Pigment coats applied, pin lined, wet & dry sanded and polished.
A total of 40 hours work over a six month period - David Platt

Photographs by David Platt.
See bottom of page for post-restoration photographs.


DESIGN HISTORY
The Step tail design is credited to John Kelly of Hawaii, circa 1962, and detailed in his excellent book, Surf and Sea, pages 139 to144. Some diagrams, images and text are reproduced below.
Apart from any performance benefits of the design, it is noteable for the early use of dropped rails and a breakaway edge in the tail.
The high aspect fin, and it's forward positioning, is also an advanced design for 1962.
He applied for and was granted US patents for the design - # 3111695 and # 3160897.
John Kelly was credited, along with Fran Heath and Wally Froiseth, with the first narrow tail template in 1934. This finless design became known as a Hot Curl, and developed to include a deep round or vee bottom in the tail.
It was the first major variation in template and/or bottom design since the revival of surfing in the 1900's.
John Kelly's account of the Hot Curl is in Surf and Sea, pages 108 to113.
The stepped tail feature was reprised by Ben Apia in his Stinger design, 1974, and was also used on some kneeboards in the late 1970's..
The hydroplane surfboard (above):
The deck contour harmonizes requirements of speed and sharp sliding angle.
Spoon- shaped bow parts chops and eliminates slapping in windy conditions;
semi-dropped rails amidship and fully dropped rails aft combine speed with high-riding capability on steep walls.
High speed planing surface (below) terminates in a sharp breakaway edge;
a critical degree of transverse bottom curvature provides balance between turning ease and stability;
the high-drag scorpion tail enables stalling and sharp turns when in contact with the water;
the axis of the skeg is angled to correspond to the pivotal axis during twistoffs.
Images and accompanying text :
Kelly : Surf and Sea, between pages 192 to193

Right :
"The hydroplane tail:
a) leanback depresses tail for high drag, slow speed and turning;
b) lean forward, tail is airborne producing minimum drag for high speed."
Diagram and text :
Kelly : Surf and Sea, page 143

Left :
John Kelly and his Hydro design,
circa 1964
Margan and Finney, page 227.


The photgraph of John kelly, above, accompanied an Advertisment for Gordon Woods Surfboards, in a Surfing World - Surfabout magazine advertisment, circa 1964.
Labelled the "Dual Purpose", the copy noted...
- Attested by R. Grigg and Wally Froiseth.
- Tested Wednesday 6th Feruary (??) in 15 ft Long Reef by Nipper Williams.
- Trials by arrangement.
- also available at Ray Richards, Newcastle...
USA  example of Step-tail design circa 1964,
imported into Australia by Gordon Woods.
Based on John Kelly's design,
the board appears remarkably similar to # 190.
The white circle on the bottom is probably a surfcraft
registration sticker.
Photograph from Surfabout magazine
Vol1 No1, page 17, and
Vol 1 No 4, page 3.
Photograph and credit details
contributed by David Platt.

Gordon Woods Surfboards
Advertisement, 1963.

    Surfabout Magazine
Volume 1 Number 3 page 17.


COMMENTS
A rare example of this design.
A case of an Australian manufacturer building an overseas design, possibly based on a photograph and probably without a credit to John Kelly.
Restoration, photographs, notes and dimensions contributed by David Platt.
Many thanks for the contibution and congratulations on the restoration to David.
REFERENCES
Books
Kelly, John : Surf and Sea, pages 139 to144.
CONDITION: Pre-restoration : 2   Post-restoration : 10
